silicon epitaxy, epi, epitaxy, epitaxial หมายถึงการเจริญเติบโตของชั้นของคริสตัลที่มีทิศทางคริสตัลเดียวกันและความหนาของคริสตัลที่แตกต่างกันบนพื้นผิวซิลิกอนผลึกเดี่ยว เทคโนโลยีการเจริญเติบโตของ Epitaxial เป็นสิ่งจำเป็นสำหรับการผลิตส่วนประกอบที่ไม่ต่อเนื่องเซมิคอนดักเตอร์และวงจรรวมเนื่องจากสิ่งสกปรกที่มีอยู่ในเซมิคอนดักเตอร์รวมถึงประเภท N และ P-type ด้วยการรวมกันของประเภทที่แตกต่างกันอุปกรณ์เซมิคอนดักเตอร์แสดงฟังก์ชั่นที่หลากหลาย
วิธีการเจริญเติบโตของ silicon epitaxy สามารถแบ่งออกเป็น epitaxy เฟสก๊าซ, epitaxy เฟสของเหลว (LPE), epitaxy เฟสโซลิด, วิธีการเจริญเติบโตของการสะสมไอสารเคมีถูกนำมาใช้อย่างกว้างขวางในโลก
อุปกรณ์ epitaxial ซิลิคอนทั่วไปแสดงโดย บริษัท LPE ของอิตาลีซึ่งมีแพนเค้ก epitaxial hy pnotic tor, ประเภทบาร์เรล hy pnotic tor, เซมิคอนดักเตอร์ hy pnotic, ผู้ให้บริการเวเฟอร์และอื่น ๆ แผนผังไดอะแกรมของห้องปฏิกิริยา Hy Pelector แบบ epitaxial รูปทรงกระบอกมีดังนี้ Vetek Semiconductor สามารถจัดหาเม็ดเลือด Hy Epitaxial Hy รูปทรงบาร์เรล คุณภาพของการเคลือบ Hy Pelector SIC นั้นเติบโตขึ้นอย่างมาก คุณภาพเทียบเท่ากับ SGL; ในเวลาเดียวกัน Vetek Semiconductor ยังสามารถให้หัวฉีดควอตซ์ของซิลิคอน epitaxial cavity quartz, baffle ควอตซ์, ขวดระฆังและผลิตภัณฑ์ที่สมบูรณ์อื่น ๆ
sic sic coated graphite barrel barrel ensceptor สำหรับ EPI
sic -coated barrel barrel
CVD SIC
LPE ถ้าผู้สนับสนุน EPI ตั้งค่า
SIC เคลือบ monocrystalline silicon epitaxial ถาด
การรองรับการเคลือบ SIC สำหรับ LPE PE2061S
การรองรับการหมุนของกราไฟท์
Veteksemicon silicon epitaxy solutions are your strategic procurement choice for advanced semiconductor wafer processing, particularly in CMOS, power devices, and MEMS applications. As a key process in wafer engineering, silicon epitaxy (Si Epi) involves the precise deposition of a crystalline silicon layer on top of a polished silicon wafer, offering superior control of doping profiles, defect density, and layer thickness.
Veteksemicon provides epitaxy-ready susceptor parts and reactor components used in Epi CVD systems, supporting both atmospheric and reduced pressure processes. Our product lineup includes silicon epitaxy susceptors, carrier rings, and coated wafer holders, optimized for compatibility with tools from Applied Materials, ASM, and Tokyo Electron (TEL).
Silicon epitaxy plays a critical role in producing ultra-thin junctions, strained silicon layers, and high-voltage isolation structures. Our materials and parts are engineered for high-purity, uniform thermal distribution, and anti-contamination performance during n-type and p-type epitaxial growth.
Closely associated terms include epitaxial wafer, in-situ doping, epitaxy-ready SiC coatings, and epi reactor parts, which support the entire upstream and downstream process of silicon-based IC fabrication.
Discover more about Veteksemicon’s silicon epitaxy support solutions by visiting our product detail page or contacting us for technical consultation and part customization.
